Ford Ecosport: Intake Air Distribution and Filtering - 2.0L Duratec-HE (129kW/175PS) / Diagnosis and Testing - Intake Air Flow

Diagnostic Trouble Code (DTC) Chart

Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices.
REFER to: Diagnostic Methods (100-00 General Information, Description and Operation).


Module DTC Description Action
PCM P0100:00 Mass or Volume Air Flow Sensor 'A' Circuit: No Sub Type Information GO to Pinpoint Test DC
PCM P0102:00 Mass or Volume Air Flow Sensor 'A' Circuit Low: No Sub Type Information GO to Pinpoint Test DC
PCM P0103:00 Mass or Volume Air Flow Sensor 'A' Circuit High: No Sub Type Information GO to Pinpoint Test DC
PCM P0104:00 Mass or Volume Air Flow Sensor 'A' Circuit Intermittent: No Sub Type Information GO to Pinpoint Test DC
PCM P0111:00 Intake Air Temperature Sensor 1 Circuit Range/Performance (Bank 1): No Sub Type Information GO to Pinpoint Test DA
PCM P0112:00 Intake Air Temperature Sensor 1 Circuit Low (Bank 1): No Sub Type Information GO to Pinpoint Test DA
PCM P0113:00 Intake Air Temperature Sensor 1 Circuit High (Bank 1): No Sub Type Information GO to Pinpoint Test DA
PCM P0114:00 Intake Air Temperature Sensor 1 Intermittent/Erratic (Bank 1): No Sub Type Information GO to Pinpoint Test DA
PCM P0505:00 Idle Control System: No Sub Type Information GO to Pinpoint Test HU
PCM P0506:00 Idle Control System - RPM Lower Than Expected: No Sub Type Information GO to Pinpoint Test HU
PCM P0507:00 Idle Control System - RPM Higher Than Expected: No Sub Type Information GO to Pinpoint Test HU
PCM P050A:00 Cold Start Idle Control System Performance: No Sub Type Information GO to Pinpoint Test HU
PCM P050B:00 Cold Start Ignition Timing Performance 'A': No Sub Type Information GO to Pinpoint Test HU
PCM P050E:00 Cold Start Engine Exhaust Temperature Too Low: No Sub Type Information GO to Pinpoint Test HU
PCM P1101:00 Mass Air Flow Sensor Out Of Self Test Range: No Sub Type Information GO to Pinpoint Test DC
PCM P1112:00 Intake Air Temperature Circuit Intermittent: No Sub Type Information GO to Pinpoint Test DA
PCM P115E:00 Throttle Actuator Control Throttle Body Air Flow Trim at Max Limit: No Sub Type Information GO to Pinpoint Test HU

Global Customer Symptom Code (GCSC) Chart

Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices.
REFER to: Diagnostic Methods (100-00 General Information, Description and Operation).


Symptom Action
Start/Run/Move > Starting > No Crank > Always GO to Pinpoint Test HU
Start/Run/Move > Starting > Slow Crank/Battery > Always GO to Pinpoint Test HU
Start/Run/Move > Starting > Hard Start/Long Crank > Always GO to Pinpoint Test HU
Start/Run/Move > Starting > Auto-Start-Stop > Inoperative GO to Pinpoint Test HU
Driving Performance > Runs Rough > Acceleration > Always GO to Pinpoint Test DC
Driving Performance > Runs Rough > Cruise/ Steady Speed > Always GO to Pinpoint Test DC
Driving Performance > Runs Rough > Deceleration > Always GO to Pinpoint Test DC
Driving Performance > Runs Rough > All Running Modes > Always GO to Pinpoint Test DA
Driving Performance > Runs Rough > All Running Modes > Always GO to Pinpoint Test DC
Driving Performance > Idle Quality > Fast > Always GO to Pinpoint Test DC
Driving Performance > Idle Quality > Fast > Always GO to Pinpoint Test HU
Driving Performance > Idle Quality > Rolling > Always GO to Pinpoint Test DC
Driving Performance > Idle Quality > Slow > Always GO to Pinpoint Test DC
Driving Performance > Idle Quality > Slow > Always GO to Pinpoint Test HU
Driving Performance > Idle Quality > Slow Return > Always GO to Pinpoint Test DC
Driving Performance > Idle Quality > Slow Return > Always GO to Pinpoint Test HU
Driving Performance > Idle Quality > Rough > Always GO to Pinpoint Test DA
Driving Performance > Idle Quality > Rough > Always GO to Pinpoint Test DC
Driving Performance > Idle Quality > Stationary Elevated Idle Control > Performance/Function GO to Pinpoint Test DC
Driving Performance > Stalls/Quits > At Idle > Always GO to Pinpoint Test DC
Driving Performance > Stalls/Quits > Acceleration > Always GO to Pinpoint Test DC
Driving Performance > Stalls/Quits > Cruise/ Steady Speed > Always GO to Pinpoint Test DC
Driving Performance > Stalls/Quits > Deceleration > Always GO to Pinpoint Test HU
Driving Performance > Lack/Loss of Power > Acceleration > Always GO to Pinpoint Test HU
Driving Performance > Lack/Loss of Power > Cruise/ Steady Speed > Always GO to Pinpoint Test HU
Driving Performance > Hesitates/Stumble > Acceleration > Always GO to Pinpoint Test DA
Driving Performance > Hesitates/Stumble > Acceleration > Always GO to Pinpoint Test DC
Driving Performance > Hesitates/Stumble > Cruise/ Steady Speed > Always GO to Pinpoint Test DC
Driving Performance > Engine Surge > At Idle > Always GO to Pinpoint Test DA
Driving Performance > Engine Surge > At Idle > Always GO to Pinpoint Test DC
Driving Performance > Engine Surge > Acceleration > Always GO to Pinpoint Test DC
Driving Performance > Engine Surge > Cruise/ Steady Speed > Always GO to Pinpoint Test DC
Driving Performance > Engine Surge > Cruise/ Steady Speed > Always GO to Pinpoint Test HU
Driving Performance > Engine Surge > Deceleration > Always GO to Pinpoint Test DC

Pinpoint Tests


PINPOINT TEST DA: INTAKE AIR TEMPERATURE (IAT) SENSOR
Introduction

Normal Operation and Fault Conditions

Refer to the DTC Fault Trigger Conditions.

DTC Fault Trigger Conditions

DTC Description Fault Trigger Condition
PCM P0111:00 Intake Air Temperature Sensor 1 Circuit Range/Performance (Bank 1): No Sub Type Information Sets when the PCM detects the IAT sensor value does not correlate with the ECT sensor value or the CHT sensor value at ignition ON after a calibrated soak period (typically 6 to 8 hours).
PCM P0112:00 Intake Air Temperature Sensor 1 Circuit Low (Bank 1): No Sub Type Information Sets when the PCM detects the IAT sensor signal is less than the self-test minimum. An IAT sensor PID reading less than the self-test minimum with ignition ON engine OFF or during any engine operating mode indicates a concern is present.
PCM P0113:00 Intake Air Temperature Sensor 1 Circuit High (Bank 1): No Sub Type Information Sets when the PCM detects the IAT sensor signal is greater than the self-test maximum. An IAT sensor PID reading greater than self-test maximum with the ignition ON engine OFF or during any engine operating mode indicates a concern is present.
PCM P0114:00 Intake Air Temperature Sensor 1 Intermittent/Erratic (Bank 1): No Sub Type Information Sets when the PCM detects the IAT sensor signal was intermittent during the Comprehensive Component Monitor (CCM). Monitor the IAT sensor value on a scan tool. Look for sudden changes in the reading when the harness is wiggled or the sensor is tapped.
PCM P1112:00 Intake Air Temperature Circuit Intermittent: No Sub Type Information Sets when the PCM detects the IAT sensor signal is intermittent. Monitor the IAT sensor PID on a scan tool. Look for sudden changes in the reading when the harness is wiggled or the sensor is tapped.

Possible Sources

  • IAT sensor circuitry concern
  • MAPT sensor circuitry concern
  • IAT sensor (12A697)
  • Integrated MAF / IAT sensor (12B579)
  • PCM (12A650)
PINPOINT TEST DC: MASS AIRFLOW (MAF) SENSOR
Introduction

Normal Operation and Fault Conditions

Refer to the DTC Fault Trigger Conditions.

DTC Fault Trigger Conditions

DTC Description Fault Trigger Condition
PCM P0100:00 Mass or Volume Air Flow Sensor 'A' Circuit: No Sub Type Information Sets when the PCM detects the MAF sensor frequency changes below a minimum calibrated limit for greater than 0.5 seconds.
PCM P0102:00 Mass or Volume Air Flow Sensor 'A' Circuit Low: No Sub Type Information Sets when the PCM detects the MAF sensor output changes below a minimum calibrated limit for greater than a set period of time during the KOER self-test.
PCM P0103:00 Mass or Volume Air Flow Sensor 'A' Circuit High: No Sub Type Information Sets when the PCM detects the MAF sensor output changes above a maximum calibrated limit while the engine is running.
PCM P0104:00 Mass or Volume Air Flow Sensor 'A' Circuit Intermittent: No Sub Type Information Sets when the PCM detects a concern with the MAF circuit, or the air tube containing the MAF sensor, causing an incorrect sensor output reading. Check the MAF sensor tube for air leaks.
PCM P1101:00 Mass Air Flow Sensor Out Of Self Test Range: No Sub Type Information Sets when the PCM detects the MAF sensor output signal is greater than a calibrated limit during KOEO , or the MAF output signal is not within the calibrated range during KOER . Diagnose circuit Diagnostic Trouble Codes (DTCs) before range or performance Diagnostic Trouble Codes (DTCs).

Possible Sources

  • MAF sensor circuitry concern
  • Intake air system leak
  • Intake air system restriction
  • MAF sensor (12B579)
  • PCM (12A650)
PINPOINT TEST HU: INTAKE AIR SYSTEMS
Introduction

Normal Operation and Fault Conditions

Refer to the DTC Fault Trigger Conditions.

DTC Fault Trigger Conditions

DTC Description Fault Trigger Condition
PCM P0505:00 Idle Control System: No Sub Type Information Sets when the PCM detects the desired RPM could not be reached or controlled during the KOER self-test. This DTC may be accompanied by other Diagnostic Trouble Codes (DTCs). Diagnose other Diagnostic Trouble Codes (DTCs) first. If no other Diagnostic Trouble Codes (DTCs) are present, inspect the intake air system for air restrictions, vacuum leaks, and damage. If no concerns are present, clear the DTC and carry out the KOER , self-test.
PCM P0506:00 Idle Control System - RPM Lower Than Expected: No Sub Type Information Sets when the PCM detects the engine idle speed is less than the desired RPM . This DTC may be accompanied by other Diagnostic Trouble Codes (DTCs). Diagnose other Diagnostic Trouble Codes (DTCs) first. If no other Diagnostic Trouble Codes (DTCs) are present, inspect the intake air system for air restrictions, vacuum leaks, and damage. If no concerns are present, clear the DTC and carry out the KOER , self-test.
PCM P0507:00 Idle Control System - RPM Higher Than Expected: No Sub Type Information Sets when the PCM detects the engine idle speed is greater than the desired RPM . This DTC may be accompanied by other Diagnostic Trouble Codes (DTCs). Diagnose other Diagnostic Trouble Codes (DTCs) first. If no other Diagnostic Trouble Codes (DTCs) are present, inspect the intake air system for air restrictions, vacuum leaks, and damage. If no concerns are present, clear the DTC and carry out the KOER , self-test.
PCM P050A:00 Cold Start Idle Control System Performance: No Sub Type Information Sets when the PCM detects the difference between desired and actual engine speed exceeds the calibrated threshold. Disregard the freeze frame data. Freeze frame data does not apply to the cold start monitor. This DTC is informational only and may be accompanied by other Diagnostic Trouble Codes (DTCs). Diagnose other Diagnostic Trouble Codes (DTCs) first. If no other Diagnostic Trouble Codes (DTCs) are present, inspect the intake air system for air restrictions, vacuum leaks, and damage. If no concerns are present, clear the Diagnostic Trouble Codes (DTCs) and verify the engine coolant temperature is below 37.8°C (100°F). Allow the vehicle to soak for 2 to 3 hours if necessary for the engine coolant temperature to fall below 37.8°C (100°F). Start the engine without touching the accelerator pedal and allow the engine to idle for 6 minutes in park. If no Diagnostic Trouble Codes (DTCs) are present and the MIL is not illuminated after idling for 6 minutes, carry out the KOER , self-test to confirm that no Diagnostic Trouble Codes (DTCs) are present and the repair is complete.
PCM P050B:00 Cold Start Ignition Timing Performance 'A': No Sub Type Information Sets when the PCM detects the difference between desired and commanded spark timing exceeds the calibrated threshold. Disregard the freeze frame data. Freeze frame data does not apply to the cold start monitor. This DTC is informational only and may be accompanied by other Diagnostic Trouble Codes (DTCs). Diagnose other Diagnostic Trouble Codes (DTCs) first. If no other Diagnostic Trouble Codes (DTCs) are present, inspect the intake air system for air restrictions, vacuum leaks, and damage. If no concerns are present, clear the Diagnostic Trouble Codes (DTCs) and verify the engine coolant temperature is below 37.8°C (100°F). Allow the vehicle to soak for 2 to 3 hours if necessary for the engine coolant temperature to fall below 37.8°C (100°F). Start the engine without touching the accelerator pedal and allow the engine to idle for 6 minutes in park. If no Diagnostic Trouble Codes (DTCs) are present and the MIL is not illuminated after idling for 6 minutes, carry out the KOER , self-test to confirm that no Diagnostic Trouble Codes (DTCs) are present and the repair is complete.
PCM P050E:00 Cold Start Engine Exhaust Temperature Too Low: No Sub Type Information Sets when the PCM detects the catalyst temperature ratio exceeds the calibrated value and the MIL illuminates. The PCM calculates the actual catalyst warm up temperature during a cold start. The PCM then compares the actual catalyst temperature to the expected catalyst temperature model. The difference between the actual and expected temperatures is a ratio. This DTC sets when this ratio exceeds the calibrated value and the MIL illuminates. Disregard the freeze frame data. Freeze frame data does not apply to the cold start monitor. This DTC is informational only and may be accompanied by other Diagnostic Trouble Codes (DTCs). Diagnose other Diagnostic Trouble Codes (DTCs) first. If no other Diagnostic Trouble Codes (DTCs) are present, inspect the intake air system for air restrictions, vacuum leaks, and damage. If no concerns are present, clear the Diagnostic Trouble Codes (DTCs) and verify the engine coolant temperature is below 37.8°C (100°F). Allow the vehicle to soak for 2 to 3 hours if necessary for the engine coolant temperature to fall below 37.8°C (100°F). Start the engine without touching the accelerator pedal and allow the engine to idle for 6 minutes in park. If no Diagnostic Trouble Codes (DTCs) are present and the MIL is not illuminated after idling for 6 minutes, carry out the KOER , self-test to confirm that no Diagnostic Trouble Codes (DTCs) are present and the repair is complete.
PCM P115E:00 Throttle Actuator Control Throttle Body Air Flow Trim at Max Limit: No Sub Type Information Sets when the PCM detects the maximum allowed compensation is reached and is no longer able to compensate for buildup. Install a new throttle body. Refer to the appropriate 303-04 section, Fuel Charging and Controls.

Possible Sources

  • Intake air system concern
  • Exhaust system concern
  • Air cleaner assembly (including air cleaner element) (9600)
  • Air inlet tube (9F843)
  • Clean air tube hose and resonator (9R504) and (9F593)
  • Throttle body assembly (9E926)
  • PCM (12A650)
