Ford Ecosport: Engine Emission Control - 2.0L Duratec-HE (129kW/175PS) / Diagnosis and Testing - Crankcase Ventilation

Ford Ecosport 2014-2024 Service and Repair Manual / Engine / Engine Emission Control - 2.0L Duratec-HE (129kW/175PS) / Diagnosis and Testing - Crankcase Ventilation

Diagnostic Trouble Code (DTC) Chart

Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices.
REFER to: Diagnostic Methods (100-00 General Information, Description and Operation).


Module DTC Description Action
PCM P2282:00 Air Leak Between Throttle Body and Intake Valves Bank 1: No Sub Type Information GO to Pinpoint Test HG

Global Customer Symptom Code (GCSC) Chart

Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices.
REFER to: Diagnostic Methods (100-00 General Information, Description and Operation).


Symptom Action
Start/Run/Move > Dipstick > Engine Oil > Missing GO to Pinpoint Test HG
Start/Run/Move > Fluids > Engine Oil > Consumption GO to Pinpoint Test HG
Start/Run/Move > Fluids > Engine Oil > Visible Leak GO to Pinpoint Test HG
Driving Performance > Runs Rough > Acceleration > Always GO to Pinpoint Test HG
Driving Performance > Runs Rough > Cruise/ Steady Speed > Always GO to Pinpoint Test HG
Driving Performance > Runs Rough > Deceleration > Always GO to Pinpoint Test HG
Driving Performance > Runs Rough > All Running Modes > Always GO to Pinpoint Test HG
Driving Performance > Idle Quality > Fast > Always GO to Pinpoint Test HG
Driving Performance > Idle Quality > Rolling > Always GO to Pinpoint Test HG
Driving Performance > Idle Quality > Slow > Always GO to Pinpoint Test HG
Driving Performance > Idle Quality > Rough > Always GO to Pinpoint Test HG
Driving Performance > Idle Quality > Stationary Elevated Idle Control > Inoperative GO to Pinpoint Test HG
Driving Performance > Stalls/Quits > At Idle > Always GO to Pinpoint Test HG
Driving Performance > Stalls/Quits > Acceleration > Always GO to Pinpoint Test HG
Driving Performance > Stalls/Quits > Cruise/ Steady Speed > Always GO to Pinpoint Test HG
Driving Performance > Spark Knock > Acceleration > Always GO to Pinpoint Test HG
Driving Performance > Spark Knock > Cruise/ Steady Speed > Always GO to Pinpoint Test HG
Driving Performance > Poor Fuel Economy > City Driving > Unloaded GO to Pinpoint Test HG
Driving Performance > Poor Fuel Economy > Highway Driving > Unloaded GO to Pinpoint Test HG
Driving Performance > Poor Fuel Economy > Combined > Unloaded GO to Pinpoint Test HG
Driving Performance > Hesitates/Stumble > Cruise/ Steady Speed > Always GO to Pinpoint Test HG
Driving Performance > Engine Surge > At Idle > Always GO to Pinpoint Test HG
Driving Performance > Engine Surge > Acceleration > Always GO to Pinpoint Test HG
Driving Performance > Engine Surge > Cruise/ Steady Speed > Always GO to Pinpoint Test HG
Driving Performance > Engine Surge > Deceleration > Always GO to Pinpoint Test HG

Pinpoint Tests


PINPOINT TEST HG: POSITIVE CRANKCASE VENTILATION (PCV) SYSTEM
Introduction

NOTE: Refer to the appropriate Wiring Diagrams Cell for schematic and connector information.

Normal Operation and Fault Conditions

Refer to the DTC Fault Trigger Conditions.

DTC Fault Trigger Conditions

DTC Description Fault Trigger Condition
PCM P2282:00 Air Leak Between Throttle Body and Intake Valves Bank 1: No Sub Type Information Sets when PCM detects an air leak that exceeds a calibrated limit for greater than 5 seconds. If the airflow entering the engine exceeds the airflow through the throttle, a leak is detected and this diagnostic fails. Verify the integrity of the PCV system. Refer to Positive Crankcase Ventilation (PCV) System for aditional information.

Possible Sources

  • Intake air system concern
  • Vacuum hose
  • Oil level indicator O-ring seal
  • Oil cap
  • PCV hose
  • PCV valve (6A666)
  • PCM (12A650)

    Description and Operation - Engine Emission Control - System Operation and Component Description

    System Operation Positive Crankcase Ventilation (PCV) System The PCV system circulates crankcase gases through the intake air system into the engine where they are burned...
